FlexiFlow Hose with PN10-40 Flanges
IMAGE DIAGRAM

FlexiFlow Hose with PN10-40 Flanges

Features

  • **Please allow 1-2 days lead time for fabrication**
  • FlexiFlow Stainless Steel Convoluted Braided Hose
  • Connection 1: PN10/16/40 (EN1092-1) Flange
  • Connection 2: PN10/16/40 (EN1092-1) Flange with Neck Ring (Floating Flange)
  • Hose Test Standard: ISO 10380-2012
  • Hose Designation: TYPE 1-10
  • Click 'View Dimensions' for the following information:
  • F = Static/Flexing Minimum Bend Radius (mm)
  • G = Working/Test Pressure (bar) *Applies to Hose Only, Not End Connections*
Code In Stock Inch Size
Code		 Metric Size
Code		 Grade A B C D E F G PRC Price QTY Quantity ST Subtotal
FFFNR25300PN10-40 1"x300
FFFNR25300PN10-40 		25.4x300
FFFNR25300PN10-40 		316 (304 BRAID) 85.0 115.0 311.0 25.4 33.7 85/190 49/73 $368.80
FFFNR25500PN10-40 1"x500
FFFNR25500PN10-40 		25.4x500
FFFNR25500PN10-40 		316 (304 BRAID) 85.0 115.0 511.0 25.4 33.7 85/190 49/73 $393.76
FFFNR25750PN10-40 1"x750
FFFNR25750PN10-40 		25.4x750
FFFNR25750PN10-40 		316 (304 BRAID) 85.0 115.0 761.0 25.4 33.7 85/190 49/73 $419.68
FFFNR251000PN10-40 1"x1000
FFFNR251000PN10-40 		25.4x1000
FFFNR251000PN10-40 		316 (304 BRAID) 85.0 115.0 1011.0 25.4 33.7 85/190 49/73 $451.36
FFFNR251500PN10-40# 1"x1500
FFFNR251500PN10-40# 		25.4x1500
FFFNR251500PN10-40# 		316 (304 BRAID) 85.0 115.0 1511.0 25.4 33.7 85/190 49/73 $527.20
FFFNR40300PN10-40 1 1/2"x300
FFFNR40300PN10-40 		38.1x300
FFFNR40300PN10-40 		316 (304 BRAID) 110.0 150.0 312.0 40.1 51.1 130/300 34/51 $592.91
FFFNR40500PN10-40 1 1/2"x500
FFFNR40500PN10-40 		38.1x500
FFFNR40500PN10-40 		316 (304 BRAID) 110.0 150.0 512.0 40.1 51.1 130/300 34/51 $638.99
FFFNR40750PN10-40 1 1/2"x750
FFFNR40750PN10-40 		38.1x750
FFFNR40750PN10-40 		316 (304 BRAID) 110.0 150.0 762.0 40.1 51.1 130/300 34/51 $697.55
FFFNR401000PN10-40 1 1/2"x1000
FFFNR401000PN10-40 		38.1x1000
FFFNR401000PN10-40 		316 (304 BRAID) 110.0 150.0 1012.0 40.1 51.1 130/300 34/51 $751.31
FFFNR401500PN10-40# 1 1/2"x1500
FFFNR401500PN10-40# 		38.1x1500
FFFNR401500PN10-40# 		316 (304 BRAID) 110.0 150.0 1512.0 40.1 51.1 130/300 34/51 $870.73
FFFNR50300PN10-16 2"x300
FFFNR50300PN10-16 		50.8x300
FFFNR50300PN10-16 		316 (304 BRAID) 125.0 165.0 312.0 50.3 62.3 160/320 29/44 $772.28
FFFNR50500PN10-16 2"x500
FFFNR50500PN10-16 		50.8x500
FFFNR50500PN10-16 		316 (304 BRAID) 125.0 165.0 512.0 50.3 62.3 160/320 29/44 $827.00
FFFNR50750PN10-16 2"x750
FFFNR50750PN10-16 		50.8x750
FFFNR50750PN10-16 		316 (304 BRAID) 125.0 165.0 762.0 50.3 62.3 160/320 29/44 $897.08
FFFNR501000PN10-16 2"x1000
FFFNR501000PN10-16 		50.8x1000
FFFNR501000PN10-16 		316 (304 BRAID) 125.0 165.0 1012.0 50.3 62.3 160/320 29/44 $970.04
FFFNR501500PN10-16# 2"x1500
FFFNR501500PN10-16# 		50.8x1500
FFFNR501500PN10-16# 		316 (304 BRAID) 125.0 165.0 1512.0 50.3 62.3 160/320 29/44 $1114.04
FFFNR65300PN10-16 2 1/2"x300
FFFNR65300PN10-16 		63.5x300
FFFNR65300PN10-16 		316 (304 BRAID) 145.0 185.0 312.0 65.6 83.0 180/410 23/35 $1008.91
FFFNR65500PN10-16 2 1/2"x500
FFFNR65500PN10-16 		63.5x500
FFFNR65500PN10-16 		316 (304 BRAID) 145.0 185.0 512.0 65.6 83.0 180/410 23/35 $1088.59
FFFNR65750PN10-16 2 1/2"x750
FFFNR65750PN10-16 		63.5x750
FFFNR65750PN10-16 		316 (304 BRAID) 145.0 185.0 762.0 65.6 83.0 180/410 23/35 $1187.47
FFFNR651000PN10-16 2 1/2"x1000
FFFNR651000PN10-16 		63.5x1000
FFFNR651000PN10-16 		316 (304 BRAID) 145.0 185.0 1012.0 65.6 83.0 180/410 23/35 $1296.91
FFFNR75300PN10-16 3"x300
FFFNR75300PN10-16 		76.2x300
FFFNR75300PN10-16 		316 (304 BRAID) 160.0 200.0 315.0 80.3 97.0 200/450 17/26 $1177.28
FFFNR75500PN10-16 3"x500
FFFNR75500PN10-16 		76.2x500
FFFNR75500PN10-16 		316 (304 BRAID) 160.0 200.0 515.0 80.3 97.0 200/450 17/26 $1262.72
FFFNR75750PN10-16 3"x750
FFFNR75750PN10-16 		76.2x750
FFFNR75750PN10-16 		316 (304 BRAID) 160.0 200.0 765.0 80.3 97.0 200/450 17/26 $1359.68
FFFNR751000PN10-16 3"x1000
FFFNR751000PN10-16 		76.2x1000
FFFNR751000PN10-16 		316 (304 BRAID) 160.0 200.0 1015.0 80.3 97.0 200/450 17/26 $1551.68
FFFNR100300PN10-16 4"x300
FFFNR100300PN10-16 		101.6x300
FFFNR100300PN10-16 		316 (304 BRAID) 180.0 220.0 319.0 100.8 119.0 290/560 15/23 $1538.86
FFFNR100500PN10-16 4"x500
FFFNR100500PN10-16 		101.6x500
FFFNR100500PN10-16 		316 (304 BRAID) 180.0 220.0 519.0 100.8 119.0 290/560 15/23 $1644.46
FFFNR100750PN10-16 4"x750
FFFNR100750PN10-16 		101.6x750
FFFNR100750PN10-16 		316 (304 BRAID) 180.0 220.0 769.0 100.8 119.0 290/560 15/23 $1773.10
FFFNR1001000PN10-16 4"x1000
FFFNR1001000PN10-16 		101.6x1000
FFFNR1001000PN10-16 		316 (304 BRAID) 180.0 220.0 1019.0 100.8 119.0 290/560 15/23 $1974.70
